| Part No. |
Name |
| 1A |
Liner for part 68 |
| 8 |
Hand guard or tail piece complete |
| 61 |
Tooth stop |
| 68 |
Head |
| 69 |
Hinge carrier (R.H.) with screws |
| 70 |
Hinge carrier (L.H.) |
| 74 |
Centering guides (2 req.) |
| 75 |
Hinges (2-req.) |
| 93 |
Side dies (2-req.) |
| 93C |
Carbide tipped side dies (2-req.)
optional at extra cost |
| 118 |
Tooth stop holder complete with washers and pin |
| 118A |
Holder Pin only |
| 142A |
Spring washer |
| 142B |
Square hole washer only |
| 142C |
Fiber washer only |
| 171-L |
Clamp screw, LH |
| 171-R |
Clamp screw, RH |
| 172 |
Bushings for handle (2-req.) |
| 174 |
Bushings for hinges (2-req.) |
| 175 |
Bolts for hinges (2-req.) |
| 2962 |
Clamping handle complete |
| 5713 |
Plastic handle |
| 6250 |
Socket head wrench set |
| 6793 |
Hand guard spacer |
